● Application
Natural wood, Bonded wood,
Plywood, Particle board






5 teeth/set
Pursuing the ultimate in quality and silence
A refined product in the
Prevent break-out burrs and flaking common to material with adhesive facing on the backside, and get finely-cut surfaces without noticeable knife marks.
These tough, wear-resistant blades can cut all types of wood material from normal lumber and birch to MDF boards and other material. The teeth use ultrafine particles and special ultra-hard alloy tips.
The unique laser-cut noise-reducing slot and newly-developed special resin plugs improved vibration control even more. The cutting noise is reduced and a high quality cutting surface is achieved.
By improving the base metal surface roughness and using a special surface treatment, this saw blade reduces the chips and debris that stick to the blade and reduces cutting resistance.
5 teeth/set (ATB with Raker)
Natural wood, Bonded wood,
Plywood, Particle board
Size | Angles | Product Code | |||||||
---|---|---|---|---|---|---|---|---|---|
Diameter | Kerf | Plate Thickness | Center hole | Teeth | A | B | C | D | |
305 | 3.0 | 2.2 | 25.4 | 100 | 15 | 15 | 15 | 10 | --TSW-3010006B-1 |
355 | 3.0 | 2.2 | 25.4 | 100 | 15 | 15 | 15 | 10 | --TSW-3510005B-1 |
5 teeth/set (ATB with Raker)
Natural wood, Bonded wood,
Plywood, Particle board
Size | Angles | Product Code | |||||||
---|---|---|---|---|---|---|---|---|---|
Diameter | Kerf | Plate Thickness | Center hole | Teeth | A | B | C | D | |
305 | 3.0 | 2.2 | 25.4 | 100 | 0 | 10 | 15 | 10 | --TSW-3010003B-2 |
330 | 3.0 | 2.2 | 25.4 | 100 | 0 | 10 | 15 | 10 | --TSW-3310001B-2 |
5 teeth/set (ATB with Raker)
Natural wood, Bonded wood,
Plywood, Particle board
Size | Angles | Product Code | |||||||
---|---|---|---|---|---|---|---|---|---|
Diameter | Kerf | Plate Thickness | Center hole | Teeth | A | B | C | D | |
305 | 3.0 | 2.2 | 25.4 | 100 | 10 | 10 | 15 | 10 | --TSW-3010002B-2 |
5 teeth/set (ATB with Raker)
Natural wood, Bonded wood,
Plywood, Particle board
Size | Angles | Product Code | |||||||
---|---|---|---|---|---|---|---|---|---|
Diameter | Kerf | Plate Thickness | Center hole | Teeth | A | B | C | D | |
305 | 3.0 | 2.2 | 25.4 | 100 | 15 | 10 | 15 | 10 | --TSW-3010001B-2 |
320 | 3.0 | 2.2 | 25.4 | 100 | 15 | 10 | 15 | 10 | --TSW-3210002B-2 |
330 | 3.0 | 2.2 | 25.4 | 100 | 15 | 10 | 15 | 10 | --TSW-3310002B-2 |
355 | 3.0 | 2.2 | 25.4 | 100 | 15 | 10 | 15 | 10 | --TSW-3510002B-2 |
